Whiteline Sway Bar Link - Bushing Kit to Suit Jeep Wrangler JK

SKU: W23452

Benefit Note: Worn or deteriorated link bushings although small can have considerable influence over sway bar performance and more notably vehicle handling behaviour. Whiteline bushings are engineered to last and deliver improved driving performance.


Kit Specifications

Bush Type 10 - Cotton Reel With & Without Tapper Bushing
Bush Quantity 4 mm
OD (A) 31 mm
ID (B) 19 mm
Length (C) 37 mm
Flange Thickness (D) 7.5 mm
Flange OD (E) 40.2 mm
C/Tube Quantity 4
C/Tube ODxIDxL 20x12.2x38 mm
Similar Bushing Size Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 10 - Cotton Reel With & Without Tapper Bushing

Bushing Design Dimensions (mm)

Bush Type 10
QTY 4
OD (A) 31
ID (B) 19
Length (C) 37.0
FL (D) 7.5
FLOD (E) 40.2
C/Tube Qty 4
C/Tube Size 20x12.2x38
Similar Bushings Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 10

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight0.338kg0.75lbs
Length7cm2.76"
Width20cm7.87"
Height14cm5.51"

Misc. Product Information

More Information
SKUW23452
Components Per4 Bushings, 4 Tubes
Kits Required1
Sub brandReplacement
Product NoteImproves stability and control, transforming vehicle performance the perfect, complete upgrade. Includes: 4 Bushings, 4 Tubes
EAN9319924392353
  • Lifetime Warranty
Brand Whiteline
SKU W23452
Unit Of Measure Kit
