Benefit Note: The Whiteline kit replaces the bushings in the rear subframe to dramatically reduce rear cross member misalignment and movement which allows a more positive feel from the rear end during cornering. Recommended for motorsport applications.

Kit Specifications

Bush Type	1 - Shackle Bushing	1 - Shackle Bushing
Bush Quantity	4 mm	4 mm
OD (A)	80 mm	80 mm
ID (B)	39.6 mm	39.6 mm
Length (C)	40.7 mm	44.2 mm
Flange Thickness (D)	9 mm	12.7 mm
Flange OD (E)	89.8 mm	89.8 mm
C/Tube Quantity	4	4
C/Tube ODxIDxL	40x19x82 mm	40x19x82 mm
Similar Bushing Size	Click Here	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Design Dimensions (mm)

Bush Type	1	1
QTY	4	4
OD (A)	80	80
ID (B)	39.6	39.6
Length (C)	40.7	44.2
FL (D)	9	12.7
FLOD (E)	89.8	89.8
C/Tube Qty	4	4
C/Tube Size	40x19x82	40x19x82
Similar Bushings	Click Here	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Packaged Weight and Dimensions

Units	cm/kg	in/lbs
Weight	2.725kg	6.01lbs
Length	40cm	15.75"
Width	10cm	3.94"
Height	20cm	7.87"

Misc. Product Information

More Information

SKU	KDT907
Components Per	8 Bushings, 4 Tubes
Kits Required	1
Sub brand	Performance
Product Note	Balances comfort with performance while minimising noise and vibrations; the perfect, complete upgrade. Includes: 8 Bushings & 4 Tubes
EAN	9319924377190
