Whiteline Rear Differential Mount - Rear Bushing Kit to Suit BMW 3 Series and M3 E36

SKU: KDT969

Benefit Note: Whiteline's differential bushing solutions ensure pinion angles are maintained while delivering an improved gear shift resulting in reduced initial torque loss and greater power transfer to the wheels.


Kit Specifications

Bush Type 1 - Shackle Bushing 1 - Shackle Bushing
Bush Quantity 2 mm 2 mm
OD (A) 51 mm 51 mm
ID (B) 34.8 mm 36 mm
Length (C) 18.3 mm 20.5 mm
Flange Thickness (D) 4.2 mm 6.4 mm
Flange OD (E) 57.2 mm 62 mm
C/Tube Quantity 2 2
C/Tube ODxIDxL 35x27x37.4 mm 35x27x37.4 mm
Similar Bushing Size Click Here Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1 - Shackle Bushing
Bushing Type 1 - Shackle Bushing

Bushing Design Dimensions (mm)

Bush Type 1 1
QTY 2 2
OD (A) 51 51
ID (B) 34.8 36
Length (C) 18.3 20.5
FL (D) 4.2 6.4
FLOD (E) 57.2 62
C/Tube Qty 2 2
C/Tube Size 35x27x37.4 35x27x37.4
Similar Bushings Click Here Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight0.52kg1.15lbs
Length7cm2.76"
Width20cm7.87"
Height14cm5.51"

Misc. Product Information

More Information
SKUKDT969
Components Per4 Bushings, 2 Tubes
Kits Required1
Sub brandPerformance
Product NoteBalances comfort with performance while minimising noise and vibrations; the perfect, complete upgrade. Includes: 4 Bushings & 2 Tubes
EAN9319924454426
  • 3 years warranty or up to 60,000km
Brand Whiteline
SKU KDT969
Unit Of Measure Kit
