Whiteline Rear Differential Mount - Bushing Kit to Suit BMW 1, 2, 3, 4 Series and X1

SKU: KDT919

Benefit Note: Whiteline's differential bushing solutions ensure pinion angles are maintained while delivering an improved gear shift resulting in reduced initial torque loss and greater power transfer to the wheels.


Kit Specifications

Bush Type 1 - Shackle Bushing 1 - Shackle Bushing
Bush Quantity 1 mm 4 mm
OD (A) 67.8 mm 49.3 mm
ID (B) 25.1 mm 24.8 mm
Length (C) 59 mm 26.3 mm
Flange Thickness (D) 6 mm 5 mm
Flange OD (E) 89.5 mm 57 mm
C/Tube Quantity 2 / 1 2 / 1
C/Tube ODxIDxL 25.4x12.2x54 / 25.4x14.3x60 mm 25.4x12.2x54 / 25.4x14.3x60 mm
Similar Bushing Size Click Here Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1 - Shackle Bushing
Bushing Type 1 - Shackle Bushing

Bushing Design Dimensions (mm)

Bush Type 1 1
QTY 1 4
OD (A) 67.8 49.3
ID (B) 25.1 24.8
Length (C) 59.0 26.3
FL (D) 6 5
FLOD (E) 89.5 57
C/Tube Qty 2 / 1 2 / 1
C/Tube Size 25.4x12.2x54 / 25.4x14.3x60 25.4x12.2x54 / 25.4x14.3x60
Similar Bushings Click Here Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight1.111kg2.45lbs
Length10cm3.94"
Width26cm10.24"
Height16cm6.3"

Misc. Product Information

More Information
SKUKDT919
Components Per5 Bushings, 3 Tubes
Kits Required1
Sub brandPerformance
Product NoteMaximises grip and stability for better control; the perfect, complete upgrade. Includes: 5 Bushings & 3 Tubes
EAN9319924387434
  • Lifetime Warranty
Brand Whiteline
SKU KDT919
Unit Of Measure Kit
