Whiteline Rear Control Arm Upper - Bushing Double Offset Camber Kit to Suit Ford Focus, Mazda3 and Volvo C30, S40

SKU: KCA394

Benefit Note: Whiteline adjustable camber kits allow for easy on-car adjustment and fine tuning of camber settings resulting in improved traction, increased cornering grip and better tyre life - ultimately improving overall performance. The kit includes low compliance synthetic elastomer bushings which maintain preferred alignment settings as well as enhanced steering response.


Kit Specifications

Bush Type 16 - Shell Without Flange Bushing
Bush Quantity 2 mm
OD (A) AI=38 AII=36.2 mm
ID (B) 22.2 mm
Length (C) 28 mm
Flange Thickness (D) 3 mm
Flange OD (E) 32 mm
C/Tube Quantity 2
C/Tube ODxIDxL 22.2x12x35 mm
Similar Bushing Size Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 16 - Shell Without Flange Bushing
Alignment Alignment Adjustment Type Alignment On Car Adjustable
Camber Eccentric Yes

Bushing Design Dimensions (mm)

Bush Type 16
QTY 2
OD (A) AI=38 AII=36.2
ID (B) 22.2
Length (C) 28.0
FL (D) 3
FLOD (E) 32
C/Tube Qty 2
C/Tube Size 22.2x12x35
Similar Bushings Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 16

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight0.332kg0.73lbs
Length7cm2.76"
Width20cm7.87"
Height14cm5.51"

Misc. Product Information

More Information
SKUKCA394
Components Per2 Shell Bushings, 2 Tubes
Kits Required1
Sub brandPerformance
Product NoteDelivers a balanced mix of comfort, precision, and durability; the perfect, complete upgrade. Includes: 2 Shell Bushings, 2 Tubes
EAN9319924346738
  • Lifetime Warranty
Brand Whiteline
SKU KCA394
Unit Of Measure Kit
