Whiteline Rear Camber/Toe Kit - 2 Bolt Design to Suit Holden Commodore VN-VZ and HSV

SKU: W63404

Benefit Note: Suffering from uneven rear tyre wear especially when lowered or when towing. The Whiteline 2 point camber / toe correction kits improve rear wheel alignment settings and saves you on replacing costly tyres.


Kit Specifications

Bush Type 1 - Shackle Bushing
Bush Quantity 4 mm
OD (A) 41.6 mm
ID (B) 24.6 mm
Length (C) 34.3 mm
Flange Thickness (D) 8.3 mm
Flange OD (E) 49.5 mm
C/Tube Quantity 2
C/Tube ODxIDxL 25.4x12.5x70.8 mm
Similar Bushing Size Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1 - Shackle Bushing
Alignment Alignment Adjustment Type Alignment On Car Adjustable
Camber / Toe Eccentric Yes

Bushing Design Dimensions (mm)

Bush Type 1
QTY 4
OD (A) 41.6
ID (B) 24.6
Length (C) 34.3
FL (D) 8.3
FLOD (E) 49.5
C/Tube Qty 2
C/Tube Size 25.4x12.5x70.8
Similar Bushings Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight0.864kg1.9lbs
Length10cm3.94"
Width26cm10.24"
Height16cm6.3"

Misc. Product Information

More Information
SKUW63404
Components Per4 Bushings, 2 Tubes
Kits Required1
Sub brandReplacement
Product NoteGreatly increases control and confidence; the perfect, complete upgrade. Includes: 4 Bushings, 2 Tubes
EAN9319924387571
  • Lifetime Warranty
Brand Whiteline
SKU W63404
Unit Of Measure Kit
