Whiteline Front Roll Centre/Bump Steer - Correction Kit to Suit Audi, Seat, Skoda and Volkswagen PQ35 Fwd/Awd

SKU: KCA472

Benefit Note: A must for lowered vehicles, Whiteline roll centre and camber adjusting correction kit, is designed to correct roll-centre geometry using specially engineered ball-joints, whilst at the same time allowing fine tunning of camber settings with up to ½ a degree of negative camber gain, perfect for track days and spirited driving! Raising the front roll-centre (along with negative camber) results in a substantial increase to front roll resistance and a significant reduction in suspension compression on the outside front tyre during cornering. The result is more even weight distribution and improved tyre contact ultimately improving front end grip, cornering speeds and tyre life when driving the vehicle to it's potential.


Kit Specifications

Bush Type
Bush Quantity
OD (A)
ID (B)
Length (C)
Flange Thickness (D)
Flange OD (E)
C/Tube Quantity
C/Tube ODxIDxL
Similar Bushing Size

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Alignment Alignment Adjustment Type Alignment On Car Adjustable
Camber / Roll Centre Offset Yes

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight1.76kg3.88lbs
Length39cm15.35"
Width10cm3.94"
Height20cm7.87"

Misc. Product Information

More Information
SKUKCA472
Components Per2 Ball Joints
Kits Required1
Sub brandPerformance
Product NoteCreates a consistent drive no matter the surface; the perfect, complete upgrade. Includes: 2 Ball Joints
EAN9319924454198
  • 3 years warranty or up to 60,000km
Brand Whiteline
SKU KCA472
Unit Of Measure Kit
