Whiteline Front Lower - Inner Rear Caster & Anti Lift Kit to Suit Hyundai I30 incl N, Kona, Veloster and Kia Cerato

SKU: KCA474

Benefit Note: Whiteline Anti Lift Kits are primarily designed to improve traction and cornering grip under power. Increasing static caster to both front wheels. The special low compliance bushings reduce caster wind-back and maintain tighter tolerances between static and dynamic alignment settings. The additional caster coupled with the firmer bushings serve to dramatically sharpen initial turn-in response - forcing more consistent alignment angles through the corner due to the reduced bush compliance.


Kit Specifications

Bush Type 16 - Shell Without Flange Bushing
Bush Quantity 2 mm
OD (A) 70.2 mm
ID (B) 14.2 mm
Length (C) 53.8 mm
Flange Thickness (D) 15 mm
Flange OD (E)
C/Tube Quantity
C/Tube ODxIDxL
Similar Bushing Size Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 16 - Shell Without Flange Bushing
Alignment Alignment Adjustment Type Alignment On Car Adjustable
Caster / Anti-Lift Eccentric No

Bushing Design Dimensions (mm)

Bush Type 16
QTY 2
OD (A) 70.2
ID (B) 14.2
Length (C) 53.8
FL (D) 15
FLOD (E)
C/Tube Qty
C/Tube Size
Similar Bushings Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 16

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight1.345kg2.97lbs
Length40cm15.75"
Width10cm3.94"
Height20cm7.87"

Misc. Product Information

More Information
SKUKCA474
Components Per2 Bushings, 2 Spacers
Kits Required1
Sub brandPerformance
Product NoteDelivers a balanced mix of comfort, precision, and durability; the perfect, complete upgrade. Includes: 2 Shell bushings, 2 Spacers
EAN9319924454846
  • 3 years warranty or up to 60,000km
Brand Whiteline
SKU KCA474
Unit Of Measure Kit
