Benefit Note: Whiteline caster kits are designed to improve cornering grip and vehicle straight line stability. This kit is supplied with dual offset bushings to give greater steering feel, more steering weight, greater precision all through increased static caster and dynamic negative camber gain. In addition, Whiteline bushings provide improved braking performance, and less under load alignment change.

Kit Specifications

Bush Type	1 - Shackle Bushing	1 - Shackle Bushing
Bush Quantity	2 mm	2 mm
OD (A)	45.7 mm	45.7 mm
ID (B)	28.4 mm	28.4 mm
Length (C)	32 mm	27.2 mm
Flange Thickness (D)	10.4 mm	5.2 mm
Flange OD (E)	54 mm	54 mm
C/Tube Quantity	2	2
C/Tube ODxIDxL	28.5x12.2x59.5 mm	28.5x12.2x59.5 mm
Similar Bushing Size	Click Here	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Alignment	Alignment Adjustment Type	Alignment On Car Adjustable
Caster	Eccentric	Yes
Caster	Eccentric	Yes

Bushing Design Dimensions (mm)

Bush Type	1	1
QTY	2	2
OD (A)	45.7	45.7
ID (B)	28.4	28.4
Length (C)	32.0	27.2
FL (D)	10.4	5.2
FLOD (E)	54	54
C/Tube Qty	2	2
C/Tube Size	28.5x12.2x59.5	28.5x12.2x59.5
Similar Bushings	Click Here	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Packaged Weight and Dimensions

Units	cm/kg	in/lbs
Weight	0.66kg	1.46lbs
Length	10cm	3.94"
Width	26cm	10.24"
Height	16cm	6.3"

Misc. Product Information

More Information

SKU	KCA382
Components Per	4 Bushings, 2 Tubes
Kits Required	1
Sub brand	Performance
Product Note	Greatly increases control and confidence; the perfect, complete upgrade. Includes: 4 Bushings, 2 Tubes
EAN	9319924342860
