Benefit Note: Whiteline Anti Lift Kits are primarily designed to improve traction and cornering grip under power. Increasing static caster to both front wheels. The special low compliance bushings reduce caster wind-back and maintain tighter tolerances between static and dynamic alignment settings. The additional caster coupled with the firmer bushings serve to dramatically sharpen initial turn-in response - forcing more consistent alignment angles through the corner due to the reduced bush compliance.

Kit Specifications

Bush Type	16 - Shell Without Flange Bushing
Bush Quantity	2 mm
OD (A)	66.3 mm
ID (B)	14.3 mm
Length (C)	60 mm
Flange Thickness (D)	13.5 mm
Flange OD (E)	40 mm
C/Tube Quantity
C/Tube ODxIDxL
Similar Bushing Size	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Alignment	Alignment Adjustment Type	Alignment On Car Adjustable
Caster	Offset	No

Bushing Design Dimensions (mm)

Bush Type	16
QTY	2
OD (A)	66.3
ID (B)	14.3
Length (C)	60.0
FL (D)	13.5
FLOD (E)	40
C/Tube Qty
C/Tube Size
Similar Bushings	Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Packaged Weight and Dimensions

Units	cm/kg	in/lbs
Weight	0.76kg	1.68lbs
Length	7cm	2.76"
Width	20cm	7.87"
Height	14cm	5.51"

Misc. Product Information

More Information

SKU	KCA437
Components Per	2 Shell Bushings
Kits Required	1
Sub brand	Performance
Product Note	Delivers a balanced mix of comfort, precision, and durability; the perfect, complete upgrade. Includes: 2 Shell Bushings
EAN	9319924390601
