Whiteline Front Bump Steer - Correction Kit to Suit Chrysler 300C and Dodge Challenger, Charger

SKU: W13327

Benefit Note: Whiteline bump steer kit is designed to change bump steer characteristics depending on driving conditions. For racing it is beneficial to reduce the amount of bump steer to give a more positive feel - sharper handling - reduced understeer.


Kit Specifications

Bush Type 1 - Shackle Bushing
Bush Quantity 4 mm
OD (A) 31.9 mm
ID (B) 21.9 (Hex) mm
Length (C) 34.7 mm
Flange Thickness (D) 6.5 mm
Flange OD (E) 40.2 mm
C/Tube Quantity 2
C/Tube ODxIDxL 22.2x12.2x70 mm
Similar Bushing Size Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1 - Shackle Bushing
Alignment Alignment Adjustment Type Alignment On Car Adjustable
Bumpsteer Offset No

Bushing Design Dimensions (mm)

Bush Type 1
QTY 4
OD (A) 31.9
ID (B) 21.9 (Hex)
Length (C) 34.7
FL (D) 6.5
FLOD (E) 40.2
C/Tube Qty 2
C/Tube Size 22.2x12.2x70
Similar Bushings Click Here

Looking for that hard-to-find part? Start your search here Whiteline Bushing Type & Size Register

Bushing Type 1

Packaged Weight and Dimensions

Unitscm/kgin/lbs
Weight0.43kg0.95lbs
Length7cm2.76"
Width20cm7.87"
Height14cm5.51"

Misc. Product Information

More Information
SKUW13327
Components Per4 Bushings, 2 Tubes
Kits Required1
Sub brandReplacement
Product NoteBoosts handling and performance, while optimising suspension geometry; the perfect, complete upgrade. Includes: 4 Bushings & 2 Tubes
EAN9319924375523
  • Lifetime Warranty
Brand Whiteline
SKU W13327
Unit Of Measure Kit
